EAS+RFID dual frequency clothing hard label
This type of product is made from ABS/PPS raw materials through a secondary injection molding process, featuring extremely strong water resistance and shock resistance. Different appearance molds can be designed according to customer requirements, with the option to embed logos and text. Utilizing RFID technology, a PCB antenna is encapsulated inside to ensure that the performance of the chip is not affected by the secondary injection molding process. Its powerful customization and uniqueness make it the ideal choice for major urban subways and transportation systems.
Product Parameters
model | HST0017 |
Support chip | FM11RF08, NTAG213, NXP-S50, H3, etc. |
Working frequency | 125KHz, 13.56MHz, 840-960MHz |
Operating distance | 2~50cm Effective distance and the read-write device and related to the environment in use |
Operating temperature | -10℃ ~ +70℃/200℃ |
Storage temperature | -20℃ ~ +80℃/220℃ |
Product specifications | 30mm(customizable according to customer requirements) |
Process Parameters
Additional process | Logos and text can be inlaid, silk-screened or laser-engraved |
Environmental protection | Compliant with ROHS directive |
Data retention | >10 years |
Erasing times | 100,000 times |
Application scenarios | Subway, bus, bus, game token, transportation payment, etc |
